    • TECHNICAL SPECIFICATIONS

    • Materials: cartridge in steel zinc plated, internal parts in hardened steel.

    • Flow range: 2 L/min;

    • Max. pressure: 250 bar (Coil 20 W)

    • Installation torque: see page 2

    • Cavity: 23081

    • Cartridge weight: see page 2

    • Coils: version C-13, see section Y

    • Oil temperature: -20°C + 80°C

    • Environment temperature: -30°C + 60°C

    • Ambient temperature range: nominal max. 10µ, ISO 4406-19/17/14 (NAS8) or less.

    • Inlet voltage fluctuations must not exceed ±10% of nominal voltage.


    • TECHNICAL SPECIFICATIONS

    • Materials: cartridge in steel zinc plated, internal parts in hardened steel.

    • Flow range: 2 L/min;

    • Max. pressure: 250 bar (Coil 20 W)

    • Installation torque: see page 2

    • Cavity: 23081

    • Cartridge weight: see page 2

    • Coils: version C-13, see section Y

    • Oil temperature: -20°C + 80°C

    • Environment temperature: -30°C + 60°C

    • Ambient temperature range: nominal max. 10µ, ISO 4406-19/17/14 (NAS8) or less.

    • Inlet voltage fluctuations must not exceed ±10% of nominal voltage.


FP-22-CS-S08-11
