  • TECHNICAL SPECIFICATIONS
    • TECHNICAL SPECIFICATIONS

    • Materials: cartridge in steel zinc plated, internal parts in hardened steel.

    • Flow range:

    • 3/4: 2-70 L/min; 1”: 4-150 L/min

    • Max. pressure: 350 bar

    • Installation torque: see page 2

    • Cavity: 21261 - 21331

    • Cartridge weight: see page 2

    • Coils: version C-13, see section Y

    • Oil temperature: -20°C + 80°C

    • Ambient temperature range: -30°C + 60°C

    • Recommended filtration: nominal max. 10µ, ISO 4406-19/17/14 (NAS8) or less.

    • Inlet voltage fluctuations must not exceed ±10% of nominal voltage.


    TECHNICAL SPECIFICATIONS
    • TECHNICAL SPECIFICATIONS

    • Materials: cartridge in steel zinc plated, internal parts in hardened steel.

    • Flow range:

    • 3/4: 2-70 L/min; 1”: 4-150 L/min

    • Max. pressure: 350 bar

    • Installation torque: see page 2

    • Cavity: 21261 - 21331

    • Cartridge weight: see page 2

    • Coils: version C-13, see section Y

    • Oil temperature: -20°C + 80°C

    • Ambient temperature range: -30°C + 60°C

    • Recommended filtration: nominal max. 10µ, ISO 4406-19/17/14 (NAS8) or less.

    • Inlet voltage fluctuations must not exceed ±10% of nominal voltage.


FP-22-CP-G*-05/06/07/08
